General Feature |
Application |
Client PCs |
Interface |
PCIe Gen 3.0 x4, NVMe 1.3 |
Storage Memory |
Samsung V-NAND 2-bit MLC |
Capacity |
1,024GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
Dimension (WxHxD) |
80.15 x 22.15 x 2.38 (mm) |
Controller |
Samsung Phoenix Controller |
Form Factor |
M.2 (2280) |
Weight |
Max 8.0 g Weight |
Cache Memory |
Samsung 1GB Low Power DDR4 SDRAM |
Special Feature |
TRIM Support |
Supported |
Encryption Support |
AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
S.M.A.R.T Support |
Supported |
WWN Support |
Not supported |
GC (Garbage Collection) |
Auto Garbage Collection Algorithm |
Device Sleep Mode Support |
Yes |
Performance |
Sequential Read |
Up to 3,500 MB/s * Performance may vary based on system hardware & configuration |
Random Write (4KB, QD32) |
Up to 500,000 IOPS * Performance may vary based on system hardware & configuration |
Sequential Write |
Up to 2,700 MB/s * Performance may vary based on system hardware & configuration |
Random Read (4KB, QD1) |
Up to 15,000 IOPS * Performance may vary based on system hardware & configuration |
Random Read (4KB, QD32) |
Up to 500,000 IOPS * Performance may vary based on system hardware & configuration |
Random Write (4KB, QD1) |
Up to 55,000 IOPS * Performance may vary based on system hardware & configuration |
Environment |
Average Power Consumption (system level) |
* Average: 5.7 W * Maximum: 8.5 W (Burst mode) * Actual power consumption may vary depending on system hardware & configuration |
Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF) |
Power consumption (Idle) |
Max. 30 mW * Actual power consumption may vary depending on system hardware & configuration |
Operating Temperature |
0 – 70 ℃ Operating Temperature |
Allowable Voltage |
3.3 V ± 5 % Allowable voltage |
Shock |
1,500 G & 0.5 ms (Half sine) |
Accessories |
Installation Kit |
Not Available |
Software |
Management SW |
Magician Software for SSD management |
Warranty |
5 Years |
