SPECIFICATIONS |
Brand |
Asus |
Series |
TUF Gaming |
Model |
90YV0FB8-M0NM00 |
Chipset |
GPU |
GeForce RTX 3080 |
Chipset Manufacturer |
NVIDIA |
Interface |
PCI-E 4.0 x16 |
Base Clock |
1440 Mhz |
Boost Clock (Gaming Mode) |
1785 MHz |
Boost Clock (OC Mode) |
1815 MHz |
CUDA Cores |
8960 |
GPU Architecture |
NVIDIA Ampere Architecture |
Memory |
Effective Memory Clock |
19Gbps |
Memory Size |
12GB |
Memory Interface |
384-bit |
Memory Type |
GDDR6X |
3D API |
DirectX |
12 Support |
OpenGL |
4.6 Support |
Vulkan |
Support |
Connectivity |
Ports |
3x DisplayPort 1.4a |
2x HDMI 2.1 |
HDCP Support |
2.3 Support |
Multi-Monitor Support |
4x Displays |
Maximum Digital Resolution |
7680 x 4320 |
VR Ready |
Yes |
General |
Features |
OC Mode |
Axial-tech Fan Design |
Dual Ball Fan Bearings |
Protective Metal Backplate |
Military-grade Capacitors |
Top-Side RGB Element |
GPU Tweak II |
Game Ready Drivers |
2nd Generation RT Cores |
3rd Generation Tensor Cores |
NVIDIA Studio Drivers |
NVIDIA DLSS |
NVIDIA Ansel |
NVIDIA Reflex |
NVIDIA G-SYNC |
NVIDIA GPU Boost |
NVIDIA Broadcast |
NVIDIA FreeStyle |
NVIDIA ShadowPlay |
NVIDIA Highlights |
NVIDIA GeForce Experience |
NVIDIA Encoder, 7th Generation |
NVIDIA Decoder, 5th Generation |
NVIDIA Ampere Streaming Multiprocessors |
Power Requirements |
Recommended Power Supply |
850W |
Power Connector |
2x 8-Pin |
Physical Aspects |
Form Factor |
ATX Form Factor |
Slot Width |
2.7 Slot |
Dimensions |
299.9 x 126.9 x 51.7mm (L x W x H) |
Warranty Information |
Warranty |
3 Year Warranty |
