SPECIFICATIONS |
Brand |
ASUS |
Series |
Dual |
Model |
Dual EVO (DUAL-RTX2060-12G-EVO) |
Chipset |
GPU |
GeForce RTX 2060 |
Chipset Manufacturer |
NVIDIA |
Interface |
PCI-E 3.0 x16 |
Base Clock |
1680 MHz |
Boost Clock |
1710 MHz |
CUDA Cores |
2176 Cores |
GPU Architecture |
NVIDIA Turing |
Memory |
Effective Memory Clock |
14 Gbps |
Memory Size |
12 GB |
Memory Interface |
192-bit |
Memory Type |
GDDR6 |
Memory Bandwidth |
336 GB/s |
3D API |
DirectX |
Microsoft DirectX 12 Ultimate |
OpenGL |
4.6 |
Vulkan |
Vulkan RT API |
Connectivity |
Ports |
1 x DisplayPort 1.4a with HDCP 2.2 |
1 x HDMI 2.0b with HDCP 2.2 |
1 x DVI-D |
Multi-Monitor Support |
4 |
Maximum Digital Resolution |
7680 x 4320 @ 60Hz |
VR Ready |
Yes |
General |
SLI Support |
N/A |
LHR (Lite Hash Rate) |
No |
Features |
ASUS Axial-Tech Fan Design |
ASUS GPU Tweak II support |
RGB Accent Strip |
Metal Backplate |
1st Gen Ray Tracing Cores |
2nd Gen Tensor Cores |
PCI Express Gen 3.0 |
Real-Time Ray Tracing Technology |
NVIDIA DLSS |
NVIDIA GeForce Experience |
NVIDIA Ansel |
NVIDIA FreeStyle |
NVIDIA ShadowPlay |
NVIDIA Highlights |
NVIDIA G-SYNC |
Game Ready Drivers |
NVIDIA Studio Drivers |
NVIDIA GPU Boost |
NVIDIA Encoder, Turing Architecture |
Package Contents |
ASUS GeForce RTX 2060 Dual EVO OC 12GB GDDR6 |
Speedsetup Manual |
Power Requirements |
Recommended Power Supply |
500 W |
Power Consumption |
Max Power Consumption |
184 W |
Max Amp Draw |
15.3 Amps (12 V Rail) |
Power Connector |
1 x 8-Pin PCIe PEG |
Operating System Support |
Windows 11 64-bit |
Windows 10 64-bit (verson 1809 or later) |
Windows 7 SP1 64-bit |
Physical Aspects |
Form Factor |
ATX |
Slot Width |
Triple Slot |
Dimensions |
242 x 130 x 53 mm (L x W x H) |
Warranty Information |
Warranty |
3 Year Warranty |
