SPECIFICATIONS |
Brand |
Western Digital |
Series |
Gold Enterprise |
Model |
WD8004FRYZ |
Specifications |
Recording Technology |
CMR (Conventional Magnetic Recording) |
Interface |
SATA 6 Gb/s |
User Sectors Per Drive |
512e |
Formatted Capacity |
8 TB |
Form Factor |
3.5″ |
Native command Queuing |
Yes |
Advanced Format |
Yes |
RoHS Compliant |
Yes |
Performance |
Sustained Transfer Rate |
255 MB/s |
Cache (MB) |
256 MB |
RPM |
7200 RPM |
Reliability |
MTBF |
2,000,000 Hours |
Workload Rate |
550 TB / Year |
Annualized Failure Rate |
0.44 % |
Power Requirements |
Read / Write |
8.8 W |
Idle |
7.4 W |
Power efficiency index (W/TB, idle) |
0.9 W / TB |
General |
Operating Temperature |
5°C to 60°C |
Non-Operating Temperature |
-40°C to 70°C |
Idle Acoustics |
29 dBA |
Seek Acoustics |
36 dBA |
Shock when Operating (half-sine wave, 2ms) |
70 G |
Shock when not Operating (half-sine wave, 2ms) |
300 G |
Physical Dimensions |
Dimensions |
26.1 x 147 x 101.6 mm (H x L x W) |
Weight |
715 grams ± 10% |
Intended Use |
Enterprise-grade data centers, Storage systems (NAS, SAN) |
Operating System Support |
Microsoft Windows, Windows Server, Linux |
Warranty Information |
Warranty |
5 Year Warranty |
